Description
Description;
- A high-frequency solar inverter with a built-in MPPT charge controller. This very new product combined an inverter and a controller which eliminates the need for numerous devices and excess cabling.
- A LCD screen to set and adjust your settings to have a better energy-efficiency Input Voltage, battery charging current and AC/Solar charger priority are configurable.
- Features;
- Pure sine wave solar inverter
- Built-in 80Amp MPPT controller
- WIFI wireless monitoring
- Running with or without battery
- Parallel without current sharing cables
- Multi-working modes; SOL, UTL, SBU
Specifications;
- Inverter Mode
- Rated Power; 3500VA/3500W
- DC Input; 24VDC,146A
- AC Output; 230VAC, 50Hz, 13A
AC Charger Mode;
- AC Input; 230VAC, 50Hz, 15A
- DC Output; 27VDC,30A
- AC Ouput; 230VAC, 50Hz, 13A
Solar Charger Mode;
- Rated Current; 80A
- System Voltage; 24VDC
- Min.Solar Voltage; 24VDC
- Best Vmp Range; 30-105VDC
- Max. Solar Voltage; 150VDC
- Model: FS-1008
- Item Code: GF-3524-FS
